| Place of Origin: | Guangdong, China (Mainland) | Model Number: | DGA24-N20 |
| Usage: | Boat, Car, Electric Bicycle, Fan, Home Appliance | Certification: | ROHS, ISO |
| Type: | Micro Motor | Torque: | 100-3500 G.cm |
| Construction: | Permanent Magnet | Commutation: | Brush |
| Protect Feature: | Drip-proof | Speed(RPM): | 6-1000 RPM |
| Continuous Current(A): | 0.12A | Output Power: | 1-5 W |
| Voltage(V): | 1.5-12 v | Efficiency: | IE 1 |
| Shaft: | Dia 2.0mm | Weight: | 10g |
| No load speed: | 100 rpm | Max efficiency: | 68.3% |
| Application: | electric lock, robot | Brush: | metal brushes |
| Style: | 24mm dc gear motor | ||
| Packaging Details: | 80PCS/TRAY, 1200PCS/CTN, CARTON DIMENSION: 11*9*6.75 INCH |
| Delivery Detail: | Within 25 days |
GM24-N20 gear motor right angle gear motor (24mm micro dc brush gear motor)
Since the establishment in 2003, there has been a commitment to the development and production of micro motors, including 4 major product series: Micro DC motor, DC gear motor, coreless motor, and brushless motor. All products are widely used in consumer electronics, electric toys, household appliances, office automation equipment, medical equipment, power tools, automotive, and other fields.
