| Model Number: | BL3650I | Usage: | Fan, Home Appliance | Type: | Micro Motor |
| Certification: | ROHS | Torque: | 25mNm | Construction: | Permanent Magnet |
| Commutation: | Brushless | Protect Feature: | Drip-proof | Speed(RPM): | 3500rpm no load |
| Continuous Current(A): | 0.18A no load | Output Power: | 1W~100W | Voltage(V): | 12V |
| Efficiency: | IE 1 | Rated load speed: | 3000rpm | Rated load torque: | 25mNm |
| Rated load current: | 0.58A | Starting torque: | 162mnm | Starting current: | 2.8A |
| Motor Length: | 50±0.3mm | Shaft dia: | 4.0mm | Application: | Air pump |
DC motor, DC gear motor, DC brushless motor, OEM and provide motor product design.
Specifications: 12V 24V 10W 15W 30W 50W 100W 150W brushless DC motor
Established in 2003, we have been committed to the development and production of micro motors, including 4 major product series: Micro DC motor, DC gear motor, coreless motor, and brushless motor.
